MegaPulse 1.2x50-12PF 12 and 39 ohm, 400-12kV, 3 sec charge time, 12 and 39 ohm virtual impedance. In accordance with the requirements in IEC 1180-1 Section 6.2; and other Standards by reference. It is acceptable for use with unpowered samples requiring a 12 or 39 ohm impedance, with no current waveform defined. It is designed to test IEC 60335, Table 7 in its entirety.This tester is in accordance with the measurement requirements of CTL DSH 251B.
The meter shows the peak of the output waveform into an open circuit. Impedance of the device being tested will attenuate this peak value. Pulse delivery one per minute for pulses above 6kV; two per minute for pulses below 6kV.
Please see Manuals Section below to view waveforms.
Allows testing to IEC 60950 Annex N/IEC 62368-1 Annex D; Line 2.
The HT-3500S RF tester is specifically designed for the challenges common to operating in the field. Along with heavy duty internal brackets and a sturdy, shock-absorbing case, this unit includes adjustable voltage output, voltage ramp, test time, leakage current and ground continuity limit settings - all controlled from an easy-to-access front panel. Call for pricing.
Perform one of the most difficult tests required with both speed and accuracy. The CDT-240 now offers a 16A option along with designed presets to implement the plug discharge test as described in IEC 61010, 60065 and 60335.
Compliance West USA is announcing the EOL (End-of-LIfe) of our MegaPulse Defib 5P series effective 07/14/2015. This unit has been replaced by our MegaPulse D5-PF advanced tester. Compliance West will continue to support, repair and calibrate the Defib 5P throughout the terms of any existing warranty agreements or up until the product's End-of-Support date. Please contact us with any questions.
